1-1022 - V3-02-29 Inner Tube Single Bend Valve
V3-02-29 Commercial Vehicle Valve
Comparative Part Numbers: V3-02-29,
Product Details
Valve Hole Size: 12.2
Length: 20+120
Bend: 94°
Legend
See the Technical Drawing for reference.
| A | B | C | α | L |
|---|---|---|---|---|
| 20mm | 120mm | 137mm | 94° | 20+120 |
